Canon CINE-SERVO 11-55mm Compact-Servo Cine Zoom Lens (Canon RF)

Canon CINE-SERVO 11-55mm Compact-Servo Cine Zoom Lens (Canon RF)

Name: Canon CINE-SERVO 11-55mm Compact-Servo Cine Zoom Lens (Canon RF)
Brand: Canon
SKU: SF-2443-B48C
Availability: InStock

Brand: Canon

MFR: 7428C001

SKU: SF-2443-B48C

Price Available Upon Request

Super 35 and Full Frame, 1.5x Extender
T2.95 and T4.4 Maximum Aperture
Suitable for 8K, HDR Image Capture
11 to 55mm Focal Range
Dual Pixel CMOS AF/AF II
Image Correction, Lens Information
V Drive Unit, Hirose 20-Pin Ports
11-Blade Iris, 2' Minimum Focus Distance

Items Included

Canon CINE-SERVO 11-55mm Compact-Servo Cine Zoom Lens (Canon RF)
Lens Cap
Dust Cap
Lens Hood
Hood Cap
19mm Lens Support Shaft
3 x Drive Unit Screw
Drive Unit Storage Bag
Limited 1-Year Manufacturer Warranty

Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks

Request Now

Categories: Lenses & Lens Accessories

The Canon RF-mount Canon CINE-SERVO 11-55mm Compact-Servo Cine Zoom Lens provides 8K and HDR-compatible imaging for Super 35 and full-frame sensor digital cinema cameras. The compact zoom features an 11-55mm focal length range and T2.95 maximum aperture natively compatible with Super 35 sensors. A built-in 1.5x extender, when engaged, expands its compatibility to full-frame sensors and extends its reach to 16.5-82.5mm with a T4.4 maximum aperture. The cinema lens series has a consistently warm color balance for accurate skin tone reproduction. An upgraded V Drive unit makes for improved focus and iris speed. The RF-mount version is compatible with Canon-specific modes like Dual Pixel CMOS AF/AF II.

Minimum Focus Distance

The 11-55mm lens can focus on objects 2' or farther away, making it ideal for mounting onto jibs, tripods, or for use in handheld shooting applications.

8K and HDR Image Support

Large-diameter aspherical lens elements and anomalous dispersion glass ensure the lens can support 8K cameras throughout its zoom range. Chromatic aberrations are controlled from the center to the edge of the image to reduce color bleeding. Internal light-shielding and coating optimization reduce ghosting and flaring.

Dual Pixel CMOS AF and AF II

The lens includes Dual Pixel CMOS AF and AF II with expanded distance measuring to reduce focusing problems when shooting in 4K. Lens position data and Dual Pixel CMOS AF/AF II combine to display focus position on your camera's UI.

Image Correction Features and Lens Information Display

When connected to your compatible camera, the CINE-SERVO's lens information is displayed on the viewfinder as well as the lens name and position. Image correction features also become available based on this information, so you can view and adjust peripheral light, magnification, chromatic aberration, distortion, and focus breathing.

Upgraded V Drive Unit

Inspired by broadcast zoom lenses, the CINE-SERVO's V Drive unit features focus breathing correction and improved servo performance. An integrated information display and USB-C terminal facilitate easy setup and maintenance of your equipment. Three Hirose 20-pin ports power the drive while enabling remote iris control. The lens supports 12-pin serial communication for standard broadcast systems. A 16-bit value encoder expands your imaging capabilities by communicating accurate positional information. This makes calibration even easier during compositing in post.

11-Blade Iris

An 11-blade iris creates a natural, circular bokeh throughout the aperture range up to T2.95. The odd number of blades creates a soft glow without any overlapping.

Maximum Aperture	T2.95 to 4.4
Lens Mount	Canon RF
Lens Format Coverage	Full-Frame (29.6 mm Image Circle)
Angle of View	Super 35 Diagonal: 100°
Focus Scales	Imperial
Filter Thread	112 mm
Zoom Ratio	5x
Minimum Focus Distance	2' / 0.6 m
Aperture/Iris Blades	11
Image Stabilization	No
Lens Mounting	No
Gear Standard	0.8 MOD
Gear Rotation	Not Specified by Manufacturer
Electronic Communication	Yes
Camera Connection	Hirose 20-Pin (LANC / Canon Lens) USB-C Hirose 12-Pin
Diameter	Front: 4.5" / 114 mm
Length	11.9" / 301 mm
Weight	6.64 lb / 3.01 kg
