Sennheiser MKH 8090 Compact Wide Cardioid Condenser Microphone

Name: Sennheiser MKH 8090 Compact Wide Cardioid Condenser Microphone
Brand: SENNHEISER
SKU: 5027
Availability: InStock

Brand: SENNHEISER

MFR: MKH 8090

Price Available Upon Request

Wide Cardioid Pattern RF Condenser
Consistent Directional Pickup
Low Self-Noise
Use as Digital Mic with MZD 8000 Module

Items Included

Sennheiser MKH 8090 Compact Wide Cardioid Condenser Microphone
MKH 8090 Microphone Head
Carrying Case

Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks

Request Now

Categories: Microphones

Part of the interchangeable 8000 series of professional microphones, the MKH 8090 from Sennheiser is a high-end, RF condenser microphone with a wide cardioid pickup pattern. It consists of a microphone head and XLR module, and is an great main microphone for situations that demand a low level of acoustic space be included in the recording.

It functions equally well as a support microphone when capturing larger groups of instruments. The microphone operates on the RF principle, delivering extremely low inherent self-noise, the ability to handle high sound pressure levels without distortion, and a high resistance to difficult climatic conditions, especially moisture.

As part of the 8000 series, the capsule is sonically identical to other microphones in the series for sound consistency across the range. A number of optional modules are available, and when used with the MZD 8000 digital module (sold separately), the microphone functions as a digital microphone with all the benefits that such a configuration brings.

Wide cardioid pickup pattern
Wide frequency response from 30 Hz to 50 kHz
Natural sound
Low inherent self-noise
Symmetrical transducer technology ensures low distortion
Transformerless, fully floating balanced output
High output signal
Rugged metal housing with non-reflective Nextel coating
Weatherproof due to high-frequency circuit
Timbrally identical with the other 8000-series microphones for optimum aural compatibility

Microphone

Form Factor	Stand/Boom Mount
Sound Field	Mono
Operating Principle	Pressure Gradient
Capsule	1 x Condenser
Polar Pattern	Subcardioid/Wide Cardioid
Pad	None
High-Pass Filter	None
Tone Adjustment	None
Indicators	None
On-Board Controls	None
Windscreen	Foam (Included)

Performance

Frequency Range	30 Hz to 50 kHz
Maximum SPL	142 dB SPL
Impedance	25 Ohms
Load Impedance	2000 Ohms
Sensitivity	-34 dBV/Pa at 1 kHz
Equivalent Noise Level	13 dB A-Weighted 23 dB CCIR

Power

Operating Voltage	48 V ± 4 V (Phantom Power)
Operating Current Consumption	3.3 mA

Physical

Color	Gray
Mounting	Mic Clip/Stand Adapter (Included)
Construction Material	Metal
Operating Temperature	14 to 140°F / -10 to 60°C
Dimensions	ø: 0.7 x L: 3" / ø: 19 x L: 75 mm
Weight	1.94 oz / 55 g
