The A20-RX from Sound Devices is a dual-channel digital receiver designed for use with the A10-TX and A20-Mini transmitters and featuring a powerful feature set that ensures professional-level reliability, even in noisy RF environments.
SpectraBand technology gives the A20-RX a massive tuning range from 470 to 1525 MHz, allowing for worldwide use, while Advanced Digital True Diversity topology uses two completely independent RF receivers for each channel, providing a total of four receiver circuits for clean reception with fewer dropouts. The system is completely digital, ensuring pristine quality audio and providing extremely long transmission distances with brick-wall SAW filters to eliminate out-of-band interference. The unit's AutoAssign function automatically scans a tuning band and selects clean, interference-free frequencies for you, saving you valuable time on set.
At a Glance
| Wireless Technology | Digital UHF |
| Diversity | True Digital Diversity |
| RF Frequency Band | 470 to 1525 MHz |
| Frequency Step Size | 25 kHz |
| RF Channel Scanning | Auto-Scan |
| Timecode Support | No |
| Latency | 2 to 3.9 ms |
| Modulation | Proprietary |
Receiver
| Receiver Type | Portable (Bag Suitable) |
| Mounting Options | Slot-Mount (with Optional Hardware) |
| Antenna | 2 x 1/4 Wave Flexible Whip, SMA (Front-Mount) |
| Number of Audio Channels | 2 |
| Audio I/O | None |
| Slot-Mount I/O Adapters | Available Separately: DB-25 (Uni/SuperSlot) |
| Audio Output Level | 14 dBu (Max) |
| Phantom Power Protection | None |
| Frequency Response | 10 Hz to 20 kHz |
| Network I/O | None |
| Network Protocols | None |
| Word Clock I/O | None |
| USB/Lightning Connectivity | None |
| Standalone Audio Interface Capable | No |
| Power Requirements | DC Input |
| DC Input Power | 6 to 18 VDC (via Mounting Slot) |
| Display & Indicators | 1 x Graphic LCD (Frequency, Multifunction, Peak, RF Level, Transmitter Battery Status) |
| Operating Temperature | 14 to 131°F / -10 to 55°C |
| Dimensions | 3.1 x 4.5 x 1" / 78.5 x 113.7 x 26.6 mm |
| Weight | 5.8 oz / 165 g (without Mounting Hardware) |
