Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher

Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher

Brand: ATOMOS

MFR: ATOMSMPR19

SKU: SF-2443-LIJG

Price Available Upon Request
  • 3840 x 2160 HDR Touchscreen Display
  • HDMI 2.0 and 12G-SDI Inputs/Outputs
  • CFexpress Type B Slot, USB-C Recording
  • Quad-Split or Switch between 4 Inputs
  • 1200 cd/m² Brightness, High Bright Mode
  • Record ProRes 12-Bit, Raw, or DNx
  • BNC, AirGlu RF, and Bluetooth TC Sync
  • Wi-Fi and Gigabit Ethernet
  • XLR Audio Input/Output
  • Optional V-Mount or Gold Mount Plates

Items Included

  • Atomos Sumo PRO-19 4K HDR Monitor-Recorder-Switcher
  • 4-Pin XLR Power Supply
  • Antenna Tip Set (Black, White, Yellow, Green, Red)
  • 2 x Wi-Fi Antenna
  • AirGlu Antenna
  • 3 x Antenna Cap
  • Desktop Feet Set
  • Hex Wrench
  • Cleaning Cloth
  • Screw Set
New Item - Coming Soon
Request Now

Categories: Monitors

With its large, bright, color-accurate 19" HDR screen and 4K recording capabilities, the Sumo PRO-194K HDR Monitor-Recorder-Switcher supports professional video workflows in both production and post-production. The Sumo's HDR capabilities enable cinematographers to realize more of a cinema camera's dynamic range when shooting in log or raw formats, and it allows you to simultaneously view all inputs, switch, and record multicamera workflows.
On-Set 4K Monitoring
On the DIT Cart
Get HDR on set in real time with on-the-fly log to HDR and PQ (Perceptual Quantizer)/HLG (Hybrid Log-Gamma) playback, complete with mission-critical monitoring tools such as waveform, focus peaking, EL Zone false color, RGB parade, vectorscope, and more on the calibrated screen. Beyond monitoring, with 8K, 6K, 4K, UHD, 2K, and 1080p raw recording, you can generate instant dailies to readily available SSD media.
1st AC Monitor
The large 19" panel gives focus pullers access to a high-quality HD image with focus assist tools such as peaking and 2:1/1:1 zoom. The robust aluminum and plastic chassis ensures that this monitor can be moved and reset for every shot during production.
Studio Monitor
In the studio, you can leverage the HDR capabilities of the Sumo PRO-19 for accurate monitoring. With a 10-stop dynamic range and 10-bit processing combined with Calibrite Display Pro or Display Plus calibration, you can be sure that your color-corrected images will translate through the post-production pipeline.
Features
Live Quad Switching and 5-Channel Recording
AtomOS provides SDI quad switching and ISO recording, which allows you to record and switch up to four ISO channels in resolutions up to 8K30, as well as record the program.
Network Connectivity
The Sumo PRO-19 features a Gigabit Ethernet connector and Wi-Fi 6E that supports NDI|HX3 for monitoring high-quality, low-latency NDI streams. It also supports AirGlu wireless timecode via Bluetooth and RF to keep sync with all your cameras on set. The monitor is also compatible with the separately available Atomos TX transmission system to wirelessly transmit video from cameras.
3D LUT Support
Sumo PRO-19 can receive a LOG signal from a camera and apply a real-time LUT (Look-Up Table) preview that approximates what the final graded image will look like in Rec. 709. Custom LUTs (.cube files) can be loaded from a CFexpress card or external USB-C storage and used in conjunction with built-in monitoring tools for precise exposure control.
Production-Grade Build Quality
The durable aluminum chassis houses multiple 1/4"-20 and 3/8"-16 mounting points around the top, bottom, and side, a rear panel 100 x 100 VESA mount, and an included stand for a variety of mounting configurations.
Versatile I/O Options
Seamlessly connect an SDI or HDMI device and convert between HDMI 2.0 and SDI (Quad 3G/6G/12G) in any combination. 3G-SDI and 12G-SDI inputs connect sources without the need for converters or four separate video inputs for multiview display or ISO recording. HDMI 2.0 supports up to 8K input and output, along with the very latest Atomos open protocol, which supports HDR automation, including the importing of camera settings. There is also support for Genlock and LTC via BNC.
High-Quality Recording
Capture the raw data stream output in ProRes Raw/Raw HQ, 10-bit Apple ProRes, H.265, or DNxHR formats.
Built-In XLR Audio
Eliminate the need for a separate audio recorder by using the full-size XLR connections to connect and power external microphones, for balanced analog audio with dedicated meters and adjustments for frame delay and gain.
Cloud Compatibility
The Sumo PRO-19 can utilize Ethernet or Wi-Fi to enhance your workflow via camera-to-cloud services, including Atomos ATOMOSphere, Adobe Frame.io, and Dropbox (with separately available service plans).
Daylight-Viewable LCD Screen
The bright 1200 cd/m² display lets you accurately monitor HDR or SD video signals, even when outside in full daylight. If additional light control is required, an optional sun hood is available separately.
Calibration
Like many high-end video monitors, the Sumo PRO-19 can be calibrated to compensate for the natural color and brightness drift that monitors exhibit over time. The Sumo's calibration input lets you use Calibrite Display Pro or Display Plus (Windows/macOS) with the separately available Atomos LANC cable (ATOMCAB018).
Power
The 4-pin XLR input provides power to the monitor using the included power supply. In the field, separately available V-mount or Gold mount plates can be used to mount up to two batteries using the additional 4-pin XLR inputs, providing ample redundant power.

Display
Panel Type
IPS-Type LCD
Display Size
19.00" / 48.3 cm
Native Resolution
3840 x 2160
Aspect Ratio
16:9
Touchscreen
Yes
Maximum Brightness
1200 nits / cd/m2
Color Support
1.07 Billion Colors (8-Bit+FRC)
HDR Support
Yes
Color Gamut
100% Rec. 709
99% DCI-P3
99% NTSC
87% Rec. 2020
LUT Support
Yes
Image Controls
Anamorphic De-Squeeze, False Color, Focus Peaking, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra
Inputs/Outputs
Video I/O
2x BNC (12G-SDI) Input
2x BNC (3G-SDI) Input
1x BNC (12G-SDI) Output
1x HDMI 2.0 Input
1x HDMI 2.0 Output
2x USB-C 3.0 / 3.1/3.2 Gen 1 Output
Embedded Audio
HDMI: 8-Channel
SDI: 12-Channel
Audio I/O
2x XLR Input
2x XLR Output
1x 1/8" / 3.5 mm Headphone Output
Built-In Speaker
No
Power I/O
1x XLR 4-Pin Input
Other I/O
1x BNC (LTC) Input
1x 2.5 mm (LANC) Input
1x RJ45 (Gigabit Ethernet) Input/Output
Media/Memory Card Slot
Single Slot: CFexpress Type B [Record/LUT/Firmware]
Wireless
Wi-Fi
Wi-Fi 6E (802.11ax)
Bluetooth
Yes
Mobile App Compatible
No
Format Support
Video Format
SDI (8/10-Bit 4:2:2)
8K Raw: 30
6K Raw: 30
4K Raw: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
2K Raw: 240/120/60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
HDMI (8/10-Bit 4:2:2)
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
Video Signal Conversion
HDMI to SDI
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
SDI to HDMI
DCI 4K: 60/50/30/25/24
UHD 4K: 60/50/30/25/24
1080p: 120/60/50/30/25/24
1080i: 60/50
720p: 60/50
Timecode Support
Yes
Recording
Pulldown Conversion
2:2, 3:2
Camera Trigger
SDI, HDMI
Pre-Roll Record
Full HD: 8 Seconds
4K: 2 Seconds
Encoding Formats
Up to 4096 x 2160
ProRes 422, 422 HQ, HQ, LT, Raw, Raw HQ at up to 60 fps
DNxHD 36, 145, 220x at up to 60 fps
DNxHR HQ, HQX, LB, SQ at up to 60 fps
H.265 HQ, LQ, MQ, SQ 8/10-Bit at up to 60 fps
Maximum Audio Tracks
12
Phantom Power
+48 V
Power
Input Power
12 to 16 VDC
Battery
Interchangeable Mount (No Plate Included)
Power Consumption
75 W
Mounting
VESA Mounting-Hole Pattern
100 x 100 mm
Tripod/Accessory Mounting
Top
4x 1/4"-20 Female
2x 3/8"-16 Female
Bottom
6x 1/4"-20 Female
3x 3/8"-16 Female
Right
4x 1/4"-20 Female
2x 3/8"-16 Female
Left
2x 1/4"-20 Female
1x 3/8"-16 Female
General
Operating Conditions
32 to 104°F / 0 to 40°C
Material of Construction
Aluminum, Plastic
Dimensions
18.7 x 12.4 x 2.4" / 47.4 x 31.5 x 6.2 cm
Weight
15.7 lb / 7.1 kg
