PORTKEYS LH5C 4K HDMI Touchscreen Monitor with Wired Camera Control

Brand: PORTKEYS

MFR: LH5C

SKU: SF-2443-EVMV

731.00

  • 5.4" HDMI 1920 x 1152 Touchscreen
  • Up to DCI 4K30 Video Input Support
  • 800 cd/m² Brightness
  • 1080p60 HDMI Output
  • Wired Camera Control
  • 3D LUT Support, L-Series Battery Plate
  • Touch Focus, 360° Color Grading
  • Anamorphic De-Squeeze, Freeze Frame

Items Included


  • PORTKEYS LH5C 4K HDMI Touchscreen Monitor with Wired Camera Control
  • USB Flash Drive
  • USB-C Camera Control Cable
  • LANC Camera Control Cable
  • Sun Hood
  • MH-2 Cold Shoe Mount
  • Storage Box
(In Stock)
Quantity

Categories: Monitors

Add pro monitoring tools and wired camera control to your camera rig with the LH5C 4K HDMI Touchscreen Monitor with Wired Camera Control from PORTKEYS. This bright, 5.4" on-camera touchscreen display offers 1920 x 1152 resolution, 800 cd/m² brightness, and the ability to input up to UHD 4K30 and output up to 1080p60 via HDMI.


Display
Panel Type
IPS-Type LCD
Display Size
5.4" / 13.7 cm
Native Resolution
1920 x 1152
Aspect Ratio
16:9
Viewing Angle
Horizontal: 160° (80/80)
Vertical: 160° (80/80)
Touchscreen
Yes
Maximum Brightness
800 nits / cd/m2
Contrast Ratio
1000:1
Color Support
1.07 Billion Colors (8-Bit+FRC)
HDR Support
No
LUT Support
Yes
Image Controls
Anamorphic De-Squeeze, Check Field, Color Temperature Selection, Focus Peaking, Histogram, Image Flip, Waveform, Zebra
Inputs/Outputs
Video I/O
1x HDMI Input
1x HDMI Output
Embedded Audio
HDMI
Audio I/O
1x 1/8" / 3.5 mm Headphone Output
Built-In Speaker
No
Power I/O
1x USB-C (24 VDC) Input
Other I/O
1x USB-A (Firmware/LUT Upload)
1x Mini-USB (Camera Control)
Media/Memory Card Slot
No
Wireless
Wi-Fi
No
Bluetooth
No
Mobile App Compatible
No
Format Support
Video Format
HDMI
DCI 4K: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
Power
Input Power
7 to 24 VDC
Battery
1x L-Series Mount on Fixed Plate
Power Consumption
7.5 W
Mounting
Tripod/Accessory Mounting
Bottom
1x 1/4"-20 Female
Left
1x 1/4"-20 Female
Right
1x 1/4"-20 Female
General
Material of Construction
Plastic
Dimensions
5.3 x 3.2 x 0.9" / 135.1 x 82.5 x 22 mm
Weight
5.7 oz / 162.00 g
Packaging Info
Package Weight
1.135 lb
Box Dimensions (LxWxH)
8.8 x 5.7 x 2.4"
