AVMATRIX 12G-SDI Fiber Optic Extender Transmitter/Receiver Set

AVMATRIX 12G-SDI Fiber Optic Extender Transmitter/Receiver Set

Name: AVMATRIX 12G-SDI Fiber Optic Extender Transmitter/Receiver Set
Brand: AVMATRIX
SKU: SF-2443-RLLY
Price: 2786 AED
Availability: InStock

Brand: AVMATRIX

MFR: FE1121-12G

SKU: SF-2443-RLLY

2,786.00 ﾹ

Up to 4K60 Signal Extender
Transmits UHD 4K60 up to 6.2 Miles
12G/6G/3G-SDI to LC Simplex Fiber Cable
Dual 12G-SDI Outputs on Receiver
SDI Equalization & Re-Clocking
Hot-Pluggable SFP Module with LC Port
2 x USB Power Supplies

Items Included

AVMATRIX 12G-SDI Fiber Optic Extender Transmitter/Receiver Set
Transmitter
Receiver
2 x USB Power Supply

Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks

Quantity

Categories: Receivers , Transmitter

The 12G-SDI Fiber Optic Extender from AV Matrix extends HD/SD signals up to 12G-SDI using your fiber optic cable network. This transmitter and receiver set has a range of up to 6.2 miles and features dual 12G-SDI outputs on the receiver. Supporting all SDI video resolutions up to 4K60 plus embedded audio and metadata, this compact set is compatible with single-mode LC simplex fiber cable.

Features include SDI equalization, hot-pluggable SFP modules with LC connectors, up to 32-channel embedded audio support, and two included USB power supplies.

Features

Extends HD/SD signals up to 12G-SDI, 4K60 over single-mode LC fiber optic cable

Supports a range of up to 6.2 miles

SDI input and loop out, LC single-mode fiber output on transmitter

LC single-mode fiber input, dual SDI outputs on receiver

Supports metadata and 32/16-channel embedded audio

Signal re-clocking

Compact, USB-powered form

Interfaces

Transmission I/O	Transmitter: 1x BNC (6G-SDI / HD-SDI / SD-SDI / 12G-SDI / 3G-SDI) Input 1x ST (6G-SDI / HD-SDI / SD-SDI / 12G-SDI / 3G-SDI) Output Receiver: 1x BNC (6G-SDI / HD-SDI / SD-SDI / 12G-SDI / 3G-SDI) Input 1x ST (6G-SDI / HD-SDI / SD-SDI / 12G-SDI / 3G-SDI) Output
Embedded Audio	SDI: 16-Channel SDI: 32-Channel
Power I/O	Transmitter: 1x Micro-USB (3.3 to 5 VDC) Input Receiver: 1x Micro-USB (3.3 to 5 VDC) Input

Standards

Video Standard Compliance	SMPTE ST-2082/424M-B/297M/ST-2081/274M/292M/296M/259M ITU -R BT.656/BT.601
Reclocking	Yes
HDCP Support	No
EDID Support	No

Transmission

Max Transmission Distance	UHD 4K: 6.2 Miles / 10 km (via Single-Mode Fiber)
Video Format	SDI : 3840 x 2160: 25/29.97/30/50/59.94/60/23.98/24 fps
Supported Cable Types	Single-Mode Fiber

Power

Power Consumption

Transmitter:
1.5 W
Receiver:
1.5 W

General

Operating Conditions	12 to 92°F / -20 to 60°C up to 90% Humidity
Storage Conditions	-22 to 158°F / -30 to 70°C
Dimensions	Transmitter: 2.8 x 1.6 x 0.9" / 71 x 41 x 23 mm
Weight	Transmitter: 7.1 oz / 200 g Receiver: 7.1 oz / 200 g
