A parfocal cine lens, the DZO Pictor 50 to 125mm T2.8 Super35 Parfocal Zoom Lens features a relatively fast maximum aperture of T2.8 with an aperture range of T2.8 to T22. As you would expect from a cinema-style zoom, the lens is parfocal, meaning it holds focus throughout the zoom range. The internal focus design with floating elements virtually eliminates focus breathing. It covers a Super35 image circle, comes standard with an interchangeable PL mount, and includes an EF mount.
The 16-blade iris creates round out-of-focus highlights, which have a more natural appearance and contribute to the lens's natural-looking bokeh. The lens features cine-style gear rings on the focus, iris, and zoom lens rings, making it compatible with cine-style lens accessories such as follow focus units, lens motors, and lens control systems. The 95mm outer front diameter allows you to use a variety of compatible third-party matte boxes, and the lens has an 86mm filter thread. A lens support foot allows you to support the lens on rods to help reduce strain on your camera's lens port.
Key Features
Focal Length | 50 to 125mm |
Lens Mount | ARRI PL |
Lens Format Coverage | Super35/APS-C |
Image Circle | 31.1 mm |
Maximum Aperture | T2.8 |
Minimum Aperture | T22 |
Diaphragm Blades | 16 |
Gear MOD & Pitch | Focus: 0.8 MOD / 32 Pitch Iris: 0.8 MOD / 32 Pitch Zoom: 0.8 MOD / 32 Pitch |
Front Diameter | 95 mm |
Filter Thread | 86 mm |
Focus Scales | Imperial |
Zoom Ratio | 2.5x |
Electronic Communication | No |
Image Stabilization | No |
Lens Support | Lens Support Foot |
Length | 6.89" / 175 mm |
Weight | 3.75 lb / 1.7 kg |
