Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)

Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)

Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)

Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)
Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)
  • For TV, Film & Broadcast Production
  • 1/2-RU Size for Cart, Bag & Rack Use
  • Use with A20-Mini & A10-TX Transmitters
  • 8-Channels, Expands to 12 or 16
  • Dante Networking, Flexible Powering
  • Full-Tuning-Range SpectraBand Technology
  • True-Diversity Reception
  • Real Time Spectrum Analyzer
  • GainForward Architecture
  • NexLink Remote-Control Link

In Stock

You Pay:
AED 53,231.44
VAT Excl.

Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)

A Versatile Multichannel Receiver Ready for the Bag, Cart, or Rack

Busy audio professionals looking for a multichannel wireless microphone receiver that can quickly and easily move between bag, cart, and rack applications will find a lot to appreciate in the A20-Nexus from Sound Devices. This 1/2-rack, 8-channel solution can be expanded to accommodate up to 16 channels and uses SpectraBand technology to provide mission-critical reliability across an ultrawide 470 to 1524 MHz tuning range—allowing it work anywhere on Earth. With a host of flexible powering options, Dante networking, and seamless integration with the Scorpio and 8-Series mixer/recorders, the A20-Nexus is packed with features to speed up your workflow, whether you're working in the field, on a production set, or at a live-performance venue.

SpectraBand + Real Time Spectral Analysis

  • SpectraBand technology delivers a tuning range of 470 to 1525 MHz in a single unit. Experience ultimate flexibility as you find open spectrum away from the crowded UHF TV band. The included A20-Monarch antennas can receive the entire 470 to 1525 MHz range, keeping your kit small and tidy and allowing you to work anywhere.
  • In addition, with Real Time Spectral Analysis, the days of waiting for a scan to complete are over. Instantly visualize the RF spectrum around you in real time and coordinate frequencies all while monitoring audio.

GainForward Transmitter Control

  • Use the GainForward architecture on the A20-Mini transmitters (available separately) to easily set the Mini's gain, low-cut, and limiter directly on your A20-Nexus or mixer-recorder.
  • This immediate, local control of gain means never having to adjust the gain on the transmitter again.

NexLink Remote Control & Dante Networking

  • Control your A20-Mini transmitter using the built-in long-range remote control link. NexLink’s advanced long-distance modulation reaches even farther than the A20-Mini’s long-range wireless audio transmission.
  • Use the built-in web server with any computer, tablet, or phone to control the A20-Nexus wherever your ethernet cable can take you. Power the receiver from a distance using Power-over-Ethernet (PoE) and remotely deliver audio via Dante. The possibilities are boundless.


  • 8-channel ultrahigh-performance, true-diversity receiver in a 1/2-rack size (8.0 x 6.6 x 1.6”).
  • Expandable to 12 or 16 channels via additional plug-in.
  • 470 to 1525 MHz tuning range via SpectraBand Technology.
  • NexLink: advanced long-distance modulation that reaches even farther than the A20-Mini’s long-range wireless audio transmission and functions separately or alongside A20-Remote.
  • Dante audio-over-IP of RF receiver audio.
  • Flexible powering: via PoE+, DC input, 8-Series, or AC mains (with optional adapter).
  • Web App control from browser on any computer, smartphone, or tablet.
  • Full remote operation capability: Power via PoE, audio via Dante, or control via Web App.
  • Dual DB-25 connectors for 16 channels of mic, line, or AES outputs.
  • Convert 16 channels of Dante to analog and/or AES on DB25 connectors, for sending IFB, voice-of-god, and more from mixer to set.
  • Wide, 6.2” color OLED touchscreen for control and monitoring.
  • Integrated Real Time Spectrum Analyzer (RTSA) and scanning for intuitive frequency coordination.
  • Optical Fiber Network option via SFP slot; SFP accepts a wide variety of modular network transceivers.
  • A20-QuickDock (available separately) allows docking and undocking in seconds from 8-Series mixer-recorders with no tools required.
  • Modular design allows A20-Nexus to be disconnected and remoted from 8-Series, as opposed to less flexible integrated RF/mixer/recorder solutions.
  • All NexLink control is handled by A20-Nexus and/or its Web App instead of the 8-Series for maximum flexibility.
  • Full remote power-down: A20-Minis can be fully powered down via NexLink for excellent battery life. This alleviates the need for remote auto-RF-power adjustment schemes. User is in full control of RF power settings.
  • Supports GainForward architecture: no gain setting on the A20-Mini transmitter. Adjust gain at the receiver or mixer.
  • 100% digital long-range modulation delivers extremely long transmission distances.
  • Excellent audio quality, full 10 Hz to 20 kHz audio bandwidth.
  • RF SAW filters for excellent rejection of interference from nearby IFB or camera-hop transmitters.
  • BNC timecode input for auto timecode sync of transmitters over NexLink.


    • Sound Devices A20-Nexus 8-Channel Digital Wireless Receiver (470 to 1524 MHz)
    • 2 x Sound Devices A20-Monarch Wideband Omnidirectional Antenna (470 to 1600 MHz)
    • Sound Devices SMA Antenna for A20-Nexus (Pair, 2.4 GHz)
    • Limited 1-Year Warranty, Extends 1 Additional Year upon Registration

Sound Devices NEXUS A20 Specs

Wireless TechnologyDigital UHF
DiversityTrue Digital Diversity
RF Frequency Band470 to 1525 MHz
Frequency Step Size25 kHz
RF Channel ScanningAuto-Scan
Timecode SupportYes
Latency2 to 3.9 ms


Receiver TypePortable (Bag Suitable)
Mounting OptionsRackmount (with Optional Hardware)
Antenna2 x BNC (Front-Mount)
2 x BNC (Rear-Mount)
2 x SMA (Rear-Mount)
2 x External, Detachable
Antenna Bias Voltage12 VDC, 200 mA (per Antenna)
Number of Audio Channels8
Audio I/O2 x DB-25 25-Pin Female Balanced Mic/Line Output (Lockable)
Audio Output Level+20 dBu (Line Level)
-20 dBu (Mic Level)
Phantom Power ProtectionNone
Frequency Response10 Hz to 20 kHz ±1 dB
Network I/O2 x RJ45
Network ProtocolsDante
Word Clock I/O1 x BNC Input
USB/Lightning Connectivity1 x USB-A Female
Standalone Audio Interface CapableNo
Power RequirementsDC Input, PoE
DC Input Power6.5 to 18 VDC
Display & Indicators1 x OLED Touchscreen (AF Level, Channel, Clip, Data Transmission, Frequency, Level, Menu Navigation, Metering, Multifunction, Mute, Output Level, Peak, Power, RF Level, Sync, Transmitter Battery Status)
Operating Temperature14 to 131°F / -10 to 55°C
Dimensions8 x 1.6 x 6.6" / 20.3 x 4 x 16.7 cm
Weight2.6 lb / 1.2 kg
