Teradek Bolt 6 LT HDMI Wireless Transmitter/Receiver Kit (Gold Mount)
Teradek Bolt 6 LT HDMI Wireless Transmitter/Receiver Kit (Gold Mount)
- SKU : #ZE7F10-2265-G | MFR : #10-2265-G | UPC : #818264028827
Features
- Transmit Video up to 750' Line-of-Sight
- Supports New 6 GHz Frequency Band
- HDMI Inputs and Outputs
- Gold Mount Battery Plate on Receiver
- Transmit up to 4K30 Video
- 10-Bit 4:2:2 Support, No Delay
- Compatible with all Bolt 4K Devices
- AES-256 Encryption, 7 x Antennas
- Bluetooth Mobile App, Spectrum Analyzer
Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks
You Pay:
AED 6,206.86
VAT Excl.
VAT Excl.
Teradek Bolt 6 LT HDMI Wireless Transmitter/Receiver Kit (Gold Mount)
Transmit and receive lossless 4K video up to 750' along line of sight with the Bolt 6 LT HDMI Wireless Transmitter/Receiver Kit from Teradek. The kit includes a wireless transmitter and receiver that can wirelessly receive up to 4K30 video with 10-bit 4:2:2 HDR support. This new Bolt 6 line supports the 6 GHz wireless band, which is now freely available. The Bolt 6 system is also compatible with all Bolt 4K devices using the 5 GHz wireless band.
The transmitter inputs up to 4K video over HDMI and the receiver outputs video via HDMI. A Gold mount battery plate is included to power the receiver with a professional Gold mount battery. A carry case is included to store and transport the kit.
Key Features
- Compatible with Bolt 6 series devices using the newly available 6 GHz frequency band
- Cross-compatible with all Bolt 4K, Bolt 4K LT, and Bolt 4K Monitor Module series devices over the 5 GHz signal spectrum
- Input and output up to 4K via HDMI video and transmit up to UHD 4K30 video
- Supports Rec 2020 HDR in 10-bit 4:2:2 color gamut
- Improved "long range" mode
- Small and lightweight chassis design
- Transmit to up to six Bolt 4K or Bolt 6 series receivers
- AES-256 encryption support
- Wireless iOS/Android app via Bluetooth features a spectrum analyzer and remote configuration
IN THE BOX
- Teradek Bolt 6 LT HDMI Wireless Transmitter/Receiver Kit (Gold Mount)
- Bolt 6 LT 750 HDMI Transmitter (Gold Mount)
- Bolt 6 LT 750 HDMI Receiver (Gold Mount)
- 2 x Battery Cover
- 2 x 2-Pin to D-Tap Power Cable (18")
- 2 x USB 2.0 Type-A Male to Type-C Male Cable (39")
- AC Adapter with Cable (6')
- 7 x Antenna
- Shoe Adapter
- 1/4"-20 Light Stand Adapter
- 2 x Screw
- Carry Case
- Limited 1-Year Warranty
Teradek LT 750 Specs
Inputs / Outputs
| Antenna I/O | Transmitter: 2 x RP-SMA Female Receiver: 5 x RP-SMA Female |
| Video I/O | Transmitter: 1 x HDMI 1.4b Input Transmitter: 1 x HDMI 1.4b Output Receiver: 1 x HDMI 1.4b Output |
| Embedded Audio | HDMI: 2-Channel |
| Audio I/O | None |
| Power | Transmitter/Receiver: 1 x LEMO 2-Pin (28 VDC) Input |
| Other I/O | Transmitter/Receiver: 1 x USB-C 2.0 Input |
| Encryption | 256-Bit AES |
Wireless
| Wireless Range | 750' / 228.6 m (Line-of-Sight) |
| Channel Bandwidth | 40 MHz, 20 MHz |
| Frequency Range | Non-DFS Frequencies US: 5.92 to 6.42 GHz US: 5.19 to 5.23 GHz US: 5.75 to 5.79 GHz DFS Frequencies US: 5.27 to 5.67 GHz |
| Latency | < 0.01 ms |
| RF Power | 23 dBm |
| Wi-Fi | None |
| Bluetooth | Yes |
Format Support
| Video Format | HDMI (10-Bit 4:4:4/4:2:2 RGB, YCC) UHD 4K: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080PsF: 30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 576p: 50 480p: 60/59.94 576i: 60 480i: 59.94 |
| Audio Format | 2-Channel 24-Bit 48 kHz |
| Timecode Support | Yes |
Power
| DC Input Power | 6 to 28 VDC |
| Battery Type | Transmitter/Receiver: 1 x Gold Mount |
| Power Consumption | Transmitter: 7 W Receiver: 6 W |
Environmental
| IP Rating | None |
| Operating Temperature | 32 to 72°F / 0 to 40°C |
General
| Material of Construction | Aluminum, Polycarbonate |
| Dimensions | Transmitter: 4.1 x 2.4 x 1.3" / 103 x 60 x 33 mm Receiver: 4.8 x 3.7 x 1.1" / 122 x 94 x 27 mm |
| Weight | Transmitter: 7.3 oz / 206 g, Excluding Battery Plate Receiver: 10.3 oz / 292 g, Excluding Battery Plate |
