Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)
Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)

Vaxis Atom 500 HDMI Wireless HD Video Transmission Kit (Basic)

Brand: VAXIS

MFR: VA20-500-TR01B

1,614.00 ﾹ

  • Transmits Wireless Video up to 500'
  • Supports up to 1080p H.265 Video
  • 1 x Transmitter and 1 x Receiver
  • HDMI Input/Outputs, HDMI Loop Out
  • USB Type-C Power Input, L-Series Plate
  • Multicast to iOS Devices via Wi-Fi
  • Adjustable Cooling Fan
  • Low-Latency OLED Display
Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks
Quantity

Categories: Wireless Transmission

With the Basic Atom 500 HDMI Wireless HD Video Transmission Kit from Vaxis you can transmit visually lossless, video signals to the Vaxis receiver with less than 1 ms latency. The transmitter sends a powerful line-of-sight signal up to 500' and it can also multicast via Wi-Fi to up to three mobile devices for monitoring.

The transmitter features one HDMI input and one HDMI loop output, and the receiver has two HDMI outputs. Together they support up to 1080p60 high-quality H.265 video transmissions. The transmitter also supports multicast over Wi-Fi to up to four mobile iOS devices using the Vaxis Vision app for monitoring.

Each unit features a bright, clear OLED display and they have a cooling fan that can be turned On and Off to prevent noise during your production. They can be powered via a USB Type-C connector with the included cable or by using a separately available L-series battery. The USB input can also be used to upgrade the firmware.

  • Transmitter and receiver kit transmits up to 1080p wireless video up to 500' line of sight
  • Transmit H.265 video with very-low latency
  • Transmitter features one HDMI input and one HDMI loop output, and the receiver features two HDMI outputs
  • Units are powered by either a USB Type-C power source or by using an L-series battery on its integrated plate
  • Multicast support for transmitting video via Wi-Fi to up to four iOS devices running the Vaxis Vision app
  • Adjustable cooling fan that can be turned on and off
  • Bright OLED screen
  • Lightweight metal housing; both units are the same size with integrated antennas
  • Cold Shoe Mount attaches with single 1/4"-20 screw

Video I/OTransmitter: 1 x HDMI Input
Transmitter: 1 x HDMI Output
Receiver: 2 x HDMI Output
HDCP SupportNot Specified by Manufacturer
Embedded AudioHDMI: 2-Channel
Audio I/ONone
PowerTransmitter: 1 x USB-C Input
Receiver: 1 x USB-C Input

Wireless

Wireless Range500' / 152.4 m (Line-of-Sight)
Frequency RangeUS: 5.1 to 5.9 GHz
Latency< 1 ms
RF Power17 dBm
RF Sensitivity-80 dBm
Wi-FiNone
BluetoothNone

Format Support

Video FormatHDMI
1080p: 60/50/30/25/24
1080i: 60/50
720p: 60
Audio FormatNot Specified by Manufacturer
Wireless Video CompressionCompressed
Timecode SupportYes

Power

DC Input Power5 VDC
Battery TypeTransmitter: 1 x L-Series
Receiver: 1 x L-Series
Power ConsumptionTransmitter: 6.5 W
Receiver: 4.5 W

Mounting

Mounting3 x 1/4"-20 Female

Environmental

IP RatingNone

General

DimensionsTransmitter/Receiver: 4.1 x 2.5 x 0.8" / 105 x 63.5 x 20 mm
WeightTransmitter: 4.7 oz / 134 g, Excluding Battery
Receiver: 4.6 oz / 130 g, Excluding Battery

Packaging Info

Package Weight1.07 lb
Box Dimensions (LxWxH)7 x 4.6 x 2.9"
