The BCJ-XP-TRC 75 Ohm to 110 Ohm Digital Audio Impedance Transformer from Canare is a transformer that passively converts 75Ω BNC coaxial cable to 110Ω/XLR3 standard AES/EBU digital audio signals. This solution is ideal for use in post-production suites, DAT routing, recording studios, and digital audio tie lines. It also permits longer cable runs in comparison with twisted pair 110Ω and additionally provides excellent rejection against hum and noise.
110Ω to 75Ω Transformer
Use this transformer to passively convert 75Ω BNC coaxial cable to a standard 110Ω/XLR3 AES/EBU digital audio signal.
Applications
This solution is well suited for use in post-production suites, DAT routing, recording studios, and digital audio tie lines, among other possible applications.
Reduced Noise
This unit provides excellent rejection against hum and noise.
| Construction | Metal |
| Finish | Silver, gray, yellow |
| Input | 1 x BNC female receptacle (75Ω) |
| Output | 1 x XLR3 male plug (110Ω) |
| Dimensions | Not specified by manufacturer |
Packaging Info
| Package Weight | 0.135 lb |
| Box Dimensions (LxWxH) | 5.95 x 2.1 x 1.2" |
