Transmits HDMI signals up to 60m at 1080p and 35m at 4K@30 using Cat 6 cable
1 x HBT-5 main unit
1 x DC to DC cable
2 x Screw
Categories: Accessories
Video/Audio Input | HDMI x1 |
Video/Audio Output | HDBaseT RJ-45 x1 |
Supported Video Format | 3840x2160p: 30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50, 720p: 60/59.94/50 525i59.94 NTSC, 625i50 PAL |
Video Process | 4K2K30 4:4:4 8bit 4K2K60 4:2:0 8bit |
Video bandwidth | Single-link 340MHz [10.2Gbps] |
DVIP | --- |
RS-422/ RS-232 | YES |
Power | DC Out: 12V 24W |
PoE Output | --- |
HDBaseT Distance | 1080p@60 60m (198ft) by CAT6 cable 4K2K@30 35m (114ft) by CAT6 cable |
HDMI compliance | HDMI Deep Color, full 3D & 4K2K@30 |
HDCP compliance | HDCP 2.2/1.4 |
Audio support | Surround sound [up to 7.1ch) or stereo digital audio |
Dimension (LxWxH) | 88 x 76 x 30 mm |
Weight | 151 g |
Operating Temp. Range | 0~40 °C |
What's in the Box | 1 x HBT-5 main unit
|
