PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control
PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control

PORTKEYS 7" HDMI/SDI High-Bright Monitor with Wireless Camera Control

Brand: PORTKEYS

MFR: LS7P

SKU: SF-2443-SCIB

Price Available Upon Request
  • 7" 1920 x 1080 Resolution Display
  • Up to DCI 4K30 Video Input via HDMI
  • Up to 1080p Video Input via 3G-SDI
  • Wireless Control of Multiple Cameras
  • 1000 cd/m² Brightness | 1000:1 Contrast
  • Multiple Built-In Imaging Tools, 3D LUTs
  • HDMI/SDI Loop Output, Headphone Jack
  • 160° Viewing Angle, Top Buttons
  • Power via L-Series Battery or DC Input
  • 1/4"-20 Mounting Thread, Back Flex Mount
Not in stock - Order now and we'll deliver when available - Normally ships in 3-4 weeks or less
Request Now

Categories: On Camera Monitors , On Camera Monitors


Display
Panel Type
LCD
Display Size
7.0" / 17.8 cm
Native Resolution
1920 x 1080
Aspect Ratio
16:9
Viewing Angle
Horizontal: 160° (80/80)
Vertical: 160° (80/80)
Touchscreen
Yes
Maximum Brightness
1000 nits / cd/m2
Contrast Ratio
1000:1
Color Support
16.7 Million Colors (8-Bit)
HDR Support
No
Color Gamut
100% Rec. 709
LUT Support
No
Image Controls
Anamorphic De-Squeeze, Check Field, Color Temperature Selection, Customizable Aspect Ratios, False Color, Focus Peaking, Histogram, Image Flip, OSD Flip, RGB Parade, Screen Markers, Waveform, Zebra
Inputs/Outputs
Video I/O
1 x HDMI (Unspecified Signal) Input
1 x BNC (3G-SDI) Input
1 x HDMI (Unspecified Signal) Output
1 x BNC (3G-SDI) Output
Embedded Audio
HDMI/SDI
Audio I/O
1x 1/8" / 3.5 mm Headphone Output
Other I/O
1x USB-A (Firmware/LUT Upload) Input
Media/Memory Card Slot
No
Wireless
Wi-Fi
Unspecified Version
Bluetooth
Yes
Mobile App Compatible
No
Format Support
Video Format
HDMI
DCI 4K: 30/29.97/25/24/23.98
UHD 4K: 30
1080p: 60/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
576p: 50
576i: 50
480p: 60/59.94
480i: 60/59.94
SDI
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50
Power
Input Power
7 to 20 VDC
Battery
1x L-Series Mount on Fixed Plate
Power Consumption
13 W
Mounting
Tripod/Accessory Mounting
Top
1x 1/4"-20 Female
Bottom
1x 1/4"-20 Female
Right
1x 1/4"-20 Female
General
Material of Construction
Aluminum
Dimensions
6.9 x 4.1 x 1.5" / 176.2 x 103.8 x 39.3 mm
Weight
14.4 oz / 409.00 g
