Brand: ROSCO
MFR: 293222500001
Categories: Light Control
The Rosco RoscoLED ARC Static White Control Box features four outputs allowing you to power, test, and control up to four RoscoLED Tape Static White flexible illumination strips (not included). The control box features DIP switches for testing your RoscoLED Tape and setting the DMX ID. It incorporates a single 5-pin XLR and a RJ45 connector for DMX input; a second RJ45 connector is for DMX output. A built-in LED indicates that a DMX signal is present. AC power input is via an optional Neutrik powerCON cable. You can power up to four controllers by daisy chaining them using optional powerCON cables.
| DMX | Input: 1 x 5-Pin XLR & 1 x RJ45 Output: 1 x RJ45 |
| Power Connectors | AC Input: 1 x Neutrik powerCON Output: 1 x Neutrik powerCON DC Output: 4 x Chogori 2-Pin |
| Voltage | Input: 90 to 264 VAC, 50/60 Hz Output: 24 VDC Rating: 300 W |
| Distance | 68.24' / 20.8 m |
| Certifications | CE RoHS ETL/cETL (UL8750, CSA 22.2 #250) |
| IP Rating | IP 20 |
| Temperature | 32 to 122°F / 0 to 50°C |
| Dimensions | 13 x 9.2 x 3.5" / 33 x 23.3 x 8.9 cm |
| Weight | 9.5 lb / 4.31 kg |
