Refined 4K with powerful exposure control
Expand your creative horizons with the HDC-3500RV, offering smooth handling and precision image technologies for simultaneous HDR and SDR production. The HDC-3500RV also features Extended Range Capture*¹ and Selectable Video Sensitivity*¹ for flexibility in challenging lighting conditions. This 2/3‑type 4K 3‑CMOS image sensor portable system camera delivers direct 4K output*² with outstanding image quality, in addition to HD 4x HFR. The built-in Variable ND filter enables seamless exposure control and creative depth-of-field expression. It also supports wireless operation, with a choice of optional outside panels for added versatility.
| Category | Spec | Details |
|---|---|---|
| General | Power Requirements | AC 240 V, 1.4 A (max.) DC 240 V, 1.05 A (max.) |
| Operating Temperature | –20°C to +45°C (–4°F to 113°F) | |
| Storage Temperature | –20°C to +60°C (–4°F to 140°F) | |
| Dimensions (W × H × D) | 138 × 268 × 363 mm | |
| Weight | 11 lb 0.4 oz (5.0 kg) | |
| Imager | Imager Type | 2/3" 4K CMOS Sensor with Global Shutter |
| Method | 3‑CMOS, RGB | |
| Effective Resolution | 3840 × 2160 (QFHD) 1920 × 1080 (HD) | |
| Electrical Characteristics | Sensitivity | F10 (1080/59.94p) F11 (1080/50p) at 2000 lx, 89.9% reflectance |
| S/N Ratio | –64 dB | |
| Geometric Distortion | Negligible (excluding lens distortion) | |
| Optical System | Spectrum System | F1.4 Prism |
| Built‑In Filters | ND Filters: Clear, Variable ND (1/3–1/256) CC Filters: Cross, 3200K, Black Mist, Extra OLPF | |
| Input / Output | CCU | Optical Fiber (×1) |
| Lens | 12‑Pin (×1) | |
| Viewfinder | 20‑Pin (×1) | |
| Audio Input | MIC 1 IN: XLR 3‑Pin (×1) MIC 2 IN: XLR 3‑Pin (×1) MIC Mode: –60 dBu to –20 dBu LINE Mode: 0 dBu | |
| Intercom | INTERCOM 1 & 2: XLR 5‑Pin (×1 each) | |
| Earphone | 4‑Pole Mini Jack (CTIA / OMTP) | |
| DC IN | XLR 4‑Pin (10.5–17 V) | |
| DC OUT | 4‑Pin (10.5–17 V, 0.5 A) 2‑Pin (10.5–17 V, 2.5 A) | |
| SDI Outputs | SDI 1: BNC (×1) SDI 2: BNC (×1) SDI 3: BNC (×1) | |
| SDI Monitor | BNC (×1) | |
| Test Out | BNC (×1) | |
| Prompter / Genlock | BNC (×1) Prompter: 1 Vp‑p, 75 Ω Genlock HD: Tri‑Level Sync Genlock SD: Black Burst (NTSC/PAL) | |
| Prompter 2 | No | |
| RET CTRL | 6‑Pin (×1) | |
| Remote | 8‑Pin (×1) | |
| Tracker | 12‑Pin (×1) | |
| Crane | 12‑Pin (×1) | |
| USB | USB 2.0 Type‑A (×1) | |
| Network Trunk | RJ‑45 (×1) | |
| Supplied Accessories | Included | Before Using This Unit (1) Operating Instructions (CD‑ROM) (1) Cable Clamp Belt (1 set) Screws (+B3×8) (2) Attached Label (1) |
