SWIT KA-B30B B-Mount to B-Mount Hot Swap Plate

SWIT KA-B30B B-Mount to B-Mount Hot Swap Plate

Name: SWIT KA-B30B B-Mount to B-Mount Hot Swap Plate
Brand: SWIT
SKU: SF-2443-BFCO
Availability: InStock

Brand: SWIT

MFR: KA-B30B

SKU: SF-2443-BFCO

Price Available Upon Request

Works with ARRI ALEXA35
B-Mount Hot Swap Plate
2 x D-Tap Regulated 14V Outputs
2-Pin LEMO Regulated 14V Output
Aluminum CNC Unibody Housing

Items Included

SWIT KA-B30B B-Mount to B-Mount Hot Swap Plate

(In Stock)

Request Now

Categories: Batteries & Power

Swap your batteries out without needing to switch off your camera using this KA-B30B B-Mount to B-Mount Hot Swap Plate from SWIT. The KA-B30B easily powers the ARRI ALEXA35 camera at 28.8V (22-33.6V), and when you remove the B-mount battery, the KA-A30B output regulates 28V to the camera for hot swapping.

The KA-B30B has 32Wh/3Ah battery cells inside and a 200W constant high load that can ensure two minutes for hot swapping with an LCD screen that displays countdown seconds when changing the battery. Once your battery is removed, a 120-second countdown begins to give you enough time to swap out the depleted battery with one that is fully charged, which then recharges the hot swap plate and resets the countdown to 120.

Key Features

28V, 32Wh 3Ah battery cells inside
200W constant high load
At least 2-minutes runtime
120-second countdown display
Two D-Tap regulated 14V outputs
2-pin LEMO regulated 14V output
USB 5V/2A power output
22 to 33.6V 8-pin input for power station hot swap
Aluminum CNC unibody housing
Multiple circuit protections

Plate Front / Battery Mount	B-Mount
Number of Battery Bays	1
Inputs/Outputs	1x LEMO 2-Pin Output 2x D-Tap/P-Tap Output 1x USB-A Output
Plate Material	Aluminum
Dimensions	5.6 x 3.7 x 2" / 143 x 93 x 50.2 mm
Weight	1.6 lb / 749 g
