Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)
Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)

Teradek CTRL.3 Three-Axis Wireless Lens Controller (Imperial)

Brand: TERADEK

MFR: 15-0047-I

12,128.00 ﾹ

  • Wireless Focus, Iris, and Zoom Control
  • Compatible with RT Motors and Receivers
  • Up to 5000' Wireless Range
  • Built-In OLED
  • Slot for Canon LP-E6 Battery
  • Built-In Lens Mapping and Data Storage
  • Bluetooth 2.4 GHz
  • Teradek RT App
  • SmallHD Monitor Interface Cable
Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks
Quantity

Categories: Wireless Lens Control Solutions , Wireless Lens Control Solutions

For precise lens control with your Teradek RT motors and receivers, the Teradek CTRL.3 Three-Axis Wireless Lens Controller can control focus, iris, or zoom with ease. The CTRL.3 has an outdoor wireless range of 5000' and an indoor wireless range of 500'. You can also use the included 5-pin monitor interface cable to connect directly to a monitor.

The large focus knob, flexible mounting options, OLED display for configuration and lens data, and its lightweight design make the CTRL.3 accessible and easy to use. It's powered by a single LP-E6 battery (available separately) which provides approximately 36 hours of usage time. Features include a lens mapping firmware update to utilize the included pre-marked focus or iris rings for quick autocalibration when switching lenses during a shoot. The CTRL.3 comes with five white discs Type-B, a 3' USB cable, a SmallHD monitor interface cable, a large case, six pre-marked focus rings, and four Iris strip sliders.

  • Run/stop control for RED (EPIC, SCARLET, WEAPON, RAVEN, etc.), ARRI (ALEXA, AMIRA, etc.), Phantom, Sony F55, and LANC cameras (Blackmagic, Canon C100/300/500, Sony FS7, etc.)
  • Knob, slider, zoom x/y, and rollers (a + b)
  • Lens data overlays on SmallHD monitors running OS3 allow you to get follow focus information directly on your monitor including focal distance, focal length, iris, and zoom
  • MDR.X, MDR.ACI, and RT iOS app Bluetooth compatibility
  • Manage, update, and configure your Teradek RT system with the Teradek RT app for iOS
  • Four 1/4"-20 threads, an ARRI rosette with M6 thread, and lanyard mount for mounting
  • Slot for a Canon LP-E6 battery (6.2 to 8.4V)
  • 5-pin locking connector for wired mode
  • USB port provides monitor interface and wired control
  • Pre-marked rings come in imperial units
  • FCC, IC, and CE certifications

Teradek RT CTRL.3 Specs

System

Number of Channels3
Maximum RangeOutdoor: 5000' / 1524 m
Indoor: 500' / 152.4 m
Wireless Frequency2.4 GHz

Receiver / Motor

BluetoothNone
Included Drive GearNone
Included MotorsNot Specified by Manufacturer
Operating Temperature-4 to 122°F / -20 to 50°C
Storage Temperature-40 to 185°F / -40 to 85°C

Transmitter / Controller

Transmission Delay2 ms
Transmitter I/O1 x LEMO 5-Pin
1 x USB-A
Camera TriggerNot Specified by Manufacturer
Battery TypeLP-E6
Material of ConstructionAluminum
Dimensions5.1 x 3.3 x 6.2" / 12.95 x 8.38 x 15.75 cm
Weight1.66 lb / 754 g

Packaging Info

Package Weight7.505 lb
Box Dimensions (LxWxH)13.7 x 10.4 x 7.2"
