Categories: Audio Connectors
With its space-saving design, the Cable Techniques Low-Profile Right-Angle Mini-XLR 3-Pin Male Connector with Adjustable Exit (Standard Outlet, Purple Cap) is ideal for use on portable recorders and field mixers in audio bags as well as for connecting microphones to small-format video cameras such as the Canon EOS C70 and Blackmagic Pocket Cinema. Its standard cap has a cable outlet that accommodates cabling with diameters up to 3.2mm while offering 60 degrees of adjustment swing around the 0 and 180° positions, allowing optimal placement in an array of configurations. This variant features gold pins, a black shell, and a purple cap.
Low-Profile Connector
Standard Cap
Cable Compatibility
| Connector | TA3M Low-Profile Mini-XLR 3-Pin Male (Right-Angle Connector) |
| Cable Outlet | 0.1" / 3.2 mm |
| Angle Adjustment | 60° Adjustment Range around 0 and 180° |
| Contact Plating | Gold |
| Screw | Grub Screw Hex Head Size: 0.04" / 0.9 mm |
| Dimensions | 0.4 x 1.0" / 10 x 25 mm |
| Weight | 0.4 oz / 11.3 g |
Packaging Info
| Package Weight | 0.025 lb |
| Box Dimensions (LxWxH) | 3.6 x 2.85 x 0.45" |
