DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)
DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)

DZOFilm X-Tract 18-28mm T8 FF Probe Zoom (0, 90 & 360°, ARRI PL)

Brand: DZOFILM

MFR: DZO-X1828ABC

36,015.00 ﾹ

  • Full Frame | T8 Maximum Aperture
  • Innovative 0, 90, and 360° Probe Zoom
  • 0.8 MOD FIZ Gears, 300° Focus Rotation
  • 2.1:1 Image Magnification
  • Versatile 73 to 100° Angle of View
  • Minimum Focus: 0.24"
  • <1.2" Front Outside Diameter
  • Compact 16.3" Length
  • ED and HRI Elements Reduce Aberrations
  • Waterproof, Dustproof, and Anti-Fog
Not in stock - Order now and we'll deliver when available - Normally ships in 2-3 weeks or less
Quantity

Categories: Lenses & Lens Accessories

Innovative 0, 90, and 360° Probe Zoom

Offering a 100 to 73° field of view, the ARRI PL-mount, X-Tract 18-28mm T8 FF Probe Zoom Lens from DZOFilm brings innovative close-up capture to your productions. This compact probe lens includes 0, 90, and 360° tubes for maximum flexibility. It measures just 16.3" in length and has a front outside diameter of less than 1.2", making it ideal for tight setups. It features a relatively fast T8 maximum aperture, a 2.1:1 maximum magnification, and a 0.24" minimum focusing distance.



Wide 18-28mm Zoom

  • This 18-28mm zoom offers an ultrawide to more midrange reach, covering most common focal lengths.
  • The wide 100 to 73° field of view supports flexible capture.

0, 90, and 360° View Tubes

  • This probe includes 0, 90, and 360° options that provide the most creative positioning.
  • A rotating ring enables even greater flexibility.

Close Capture in Narrow Spaces

  • Craft creative shots using a maximum magnification ratio of 2.1:1.
  • The extremely close minimum focusing distance of around 0.24" lets you get super tight coverage of your subject.
  • The large depth of field and wide-angle focal length combine to enable close-ups in constricted areas while maintaining a safe distance from your subject.

Low-Distortion, High-Resolution Optics

  • The optical design has both ED (extra-low dispersion) and high-refractive index elements, suppressing chromatic and spherical aberrations.
  • Advanced coatings help minimize flaring and reflections.
  • Incorporates seven HRI (high-refractive-index) lens elements, producing more natural color.
  • ±2% distortion control across the zoom range.

T8 Maximum Aperture

  • The relatively fast T8 maximum aperture is maintained throughout the zoom range.
  • Multilayer, antireflective coatings help ensure sharp, clear images even when shooting wide open.

Waterproof, Cine-Style Design

  • Focus, iris, and zoom functions all have 0.8 MOD cine-style gears for compatibility with follow focus and lens motor systems.
  • A lightweight yet rear-heavy design helps reduce vibrations while shooting.
  • The focus barrel offers a wide 300° rotation for precise focus pulls.
  • Waterproof and dustproof, this probe lens is also scratch and fog resistant.

Maximum ApertureT8
Minimum ApertureT22
Lens MountARRI PL
Interchangeable MountNo
Lens Format CoverageFull-Frame
Angle of ViewFull Frame
Horizontal: 100 to 73°
Focus ScalesMetric
Zoom Ratio1.56x
Magnification2.1:1 Macro Reproduction Ratio
0.47x Magnification
Image StabilizationNo
Lens Mounting1x 1/4"-20 (via Included Support Foot)
3x 3/8"-16 (via Included Support Foot)
Gear RotationFocus: 300°
Electronic CommunicationNo
DiameterFront: 1.2" / 30 mm
Length16.3" / 415 mm
Weight2.38 lb / 1.08 kg
