Icon Pro Audio Harrison 32Ci USB-C Audio/MIDI Interface

Icon Pro Audio Harrison 32Ci USB-C Audio/MIDI Interface

Name: Icon Pro Audio Harrison 32Ci USB-C Audio/MIDI Interface
Brand: ICON
SKU: SF-2443-UWXY
Availability: InStock

Brand: ICON

MFR: HAR32CI

SKU: SF-2443-UWXY

Price Available Upon Request

For Musicians, Producers, and Engineers
12 VDC Adapter / Mac, Windows, Mobile
Two 32C Mic / Line / Hi-Z Preamps
Two Line Inputs, 8-Channel ADAT I/O
Two Headphone Outs, Four Monitor Outs
24-Bit / 192 kHz AD/DA Conversion
32C Hi- and Low-Pass Filters with Bump
129 dB Dynamic Range
MIDI I/O, Built-In DSP Plug-In Host
32C Plug-In Bundle + Additional Software

Items Included

Icon Pro Audio Harrison 32Ci USB-C Audio/MIDI Interface
Power Adapter
USB-C Cable
Bitwig Studio 8 Track (Download)
Tracktion DAW Essentials (Download)
Harrison Vocal Intensity Processor (Download)
Dotec Plug-Ins (Download)
Kilohearts Bundle (Download)

Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks

Request Now

Categories: Studio Recording

The iCON 32Ci is a 12-input / 12-output USB-C audio and MIDI interface featuring a pair of Harrison 32C preamps and a pair of 32C filters, just like the ones used on some of the most iconic albums in history from artists including Michael Jackson, Paul Simon, AC/DC, Genesis, Janet Jackson, ELO, Led Zeppelin, and more.

Ready for use with Mac or Windows computers, this compact and portable interface offers a pair of XLR/TRS inputs to accommodate microphones, line signals, and Hi-Z instruments along with a second pair of TRS line inputs. Also on the rear panel are four TRS outputs allowing you to connect two sets of stereo monitors, and there's a convenient Alt Speaker switch in the Monitor section. The front panel features two independent headphone jacks, allowing performers to hear custom mixes from supported DAWs. Studio-grade AD/DA delivers a dynamic range of 129 dB, and resolutions up to 24-bit / 192 kHz are supported. In addition to the analog connections, a pair of ADAT ports supply up to eight additional channels of digital I/O, making the 32Ci an expandable studio centerpiece—especially with the smartly designed top panel layout of buttons and knobs providing tactile, intuitive control over recording and mixing functions.

32Ci Preamp

Renowned for their warm and transparent sound, the Harrison 32C preamps are a true gem in the recording world. Experience the exceptional clarity they provide, delivering a clean and detailed signal with minimal noise—perfect for a wide array of recording needs. Equipped with high-quality transformers, these preamps infuse your recordings with a rich, musical character, adding depth and warmth to every track.
The 32C preamps boast a broad frequency response, capturing subtle nuances and dynamic range with stunning precision. With 70 dB of gain, these preamps handle high input levels without distortion, making them the ideal choice for recording powerful sources like drums and electric guitars. The 32Ci offers individually selectable phantom power on each channel with a -20 dB pad that can be engaged for recording louder sources.

32Ci Filter

The 32 Series consoles revolutionized the industry with their innovative high-pass and low-pass filters, designed to tackle unwanted rumble and hiss in your sources. With dual log potentiometers, these unique filters offer an exceptionally wide sweep range, allowing you to overlap them effectively and eliminate the passband altogether. Mixing engineers, including the acclaimed Bruce Swedien, harnessed this capability to optimize their mixes, seamlessly blending multiple instruments without interference.
Discover the Bump button, meticulously recreated to emulate the original filter’s slight resonance. Experience an added punch in the low-end, just above the filter’s cutoff frequency. Use this feature strategically to retain vocal presence while expertly filtering out any unwanted rumble captured by the microphone.

iCON I/O Pro Software

iCON I/O Pro is a virtual mixer and plug-in host for iCON Pro Audio interfaces and functions as the ultimate audio control hub for your computer. Seamlessly transport audio across your system, harness the power of plug-ins both within and outside a DAW, and conveniently store your preferred plug-in chains as presets. Whether you’re recording, mixing, podcasting, streaming, or engaging with audio in any way on your computer, this feature-rich tool empowers you to achieve professional-grade results with ease.
The 32Ci features UNI, iCON Pro Audio’s proprietary protocol designed for seamless live-streaming device connection via the equipped USB port (OTG). With UNI, you’ll enjoy unparalleled stability, ensuring a supersmooth and reliable streaming experience like never before.

Bundled with Software and Plug-Ins

Included with the interface are the Harrison Vocal Intensity Processor, an 8-track version of the Bitwig Studio DAW, a package of Dotec Audio plug-ins, the Kilohearts Toolbox bundle, and the Tracktion DAW Essentials set.

At a Glance

Two 32C console-grade analog mic preamps and console-grade 32C filters, (as used by Michael Jackson, Paul Simon, Genesis, and AC/DC on the original 32C console)
32C mic/instrument preamps complimented by individual gain control and phantom power
Bump control for retaining presence while cutting low frequencies as featured on later modifications to the original 32C analog desk
Pad switch for -20 dB signal attenuation
Supports resolutions / sampling rates up to 24-bit / 192 kHz
2 mic-in / 2 inst-in + ADAT connectivity = 12 in x 12 out capability
4×4 analog I/O full duplex simultaneous recording and playback
High-end studio-grade AD/DA providing a super high dynamic range of 129 dB
Supports Mac/PC connectivity simultaneously with smart devices
Live sessions possible with audio signal processing via ProDriver virtual plug-in rack
Compatible with iOS and Android via USB-C digital or 3.5mm analog connector for direct connection with smart phones, tablets, and other devices
Four analog outputs on 1/4” TRS jacks
Two MIDI in/out 5-pin DIN connectors
Monitor volume control knob
Alternate button for switching between different monitoring setups
Extremely well built and robust switch gear and surfaces
Two headphone outputs with individual volume controls
Flexible channel routing via the ProDriver software control panel
ICON Pro Audio developed ultralow latency ProDriver driver included
ICON Pro Audio’s innovative and user friendly plug-in hosting rack software built-in with ProDriver (Windows and Mac)
ARM-M7 / 500 MHz processing power and technology for superfast and extremely stable signal processing—two instances of the chip are used, one for the USB connection and one for mobile devices via the independent USB-C connector at the rear
+4 / -10 button for TRS inputs 3 and 4
Supports Direct Sound, WDM, and ASIO 2.0
Loopback function is possible with ProDriver for both Mac and Windows platforms
Class-compliant with MacOS 10.15 or above and Windows 10 or above
+12 VDC power supply included
Rugged, high quality construction
Aluminum chassis with vintage analog aesthetic

General

Display	No
Channels of I/O	Analog: 4 Inputs / 4 Output at 192 kHz Digital: 8 Inputs / 8 Outputs
Built-In DSP	2x 500 MHz ARM M7
Maximum Sampling Rate	192 kHz / 24-Bit
Number of Microphone Inputs	2
Built-In Microphone	No
Input Level Adjustment	2x Knob

Signal Processing

Pad	-20 dB (Switchable per Channel)
Gain/Trim Range	Combo XLR-1/4" Mic Inputs: 70 dB
Solo/Mute	No

Connectivity

Analog Audio I/O	2x Combo XLR-1/4" TRS Balanced Mic/Line/Hi-Z Input 2x 1/4" TRS Balanced Line Input 4x 1/4" TRS Balanced Line Output 2x 1/4" TRS Headphone Output
Phantom Power	48 V, Selectable On/Off (Selectable on Individual Inputs)
Digital Audio I/O	1x TOSLINK Optical ADAT Input 1x TOSLINK Optical ADAT Output
Host Connection	1x USB-C 1x USB-C (Class-/USB OTG-Compliant)
Host Connection Protocol	USB 2.0
USB (Non-Host)	1x USB-C
Sync I/O	No
Network I/O	No
MIDI I/O	1x DIN 5-Pin Input 1x DIN 5-Pin Output
Expansion Slots	No
Wireless	No

Performance

Frequency Response	Combo XLR-1/4" Mic, Line Inputs: 20 Hz to 20 kHz
Maximum Input Level	+18 dBu (with Pad)
Maximum Output Level	+21 dBu
Impedance	XLR Mic Inputs: 1200 Ohms
Dynamic Range	125 dBA
SNR	-125 dBA
THD+N	-117 dB
