Sennheiser SpeechLine Digital Wireless Microphone Set with 153-S DW Stand, MEG 14-40-L-II B Microphone, and DW Receiver (US)

Name: Sennheiser SpeechLine Digital Wireless Microphone Set with 153-S DW Stand, MEG 14-40-L-II B Microphone, and DW Receiver (US)
Brand: SENNHEISER
SKU: SF-2443-HVFB
Availability: InStock

Brand: SENNHEISER

MFR: SL TS 153 GN-L SET DW-4 US

SKU: SF-2443-HVFB

Price Available Upon Request

SL Table Stand 153-S DW
MEG 14-40-L-II B Gooseneck Microphone
SL Rack Receiver DW
BA 40 Rechargeable Battery
Up to 10 Hours of Operation
1920 to 1930 MHz Frequency Range
Rackmount Included
Suitable for Conference Rooms
Easy Wireless Charging
LED Battery Indicator

Items Included

Sennheiser SpeechLine Digital Wireless Microphone Set with 153-S DW Stand, MEG 14-40-L-II B Microphone, and DW Receiver (US)
SL Table Stand 153-S DW
MEG 14-40-L-II B Gooseneck Microphone
BA 40 Accupack
SL Rack Receiver DW
Power Supply
GA 4 Rackmount Kit
USB Cable

Not in stock - Order now and we'll deliver when available - Normally ships in 4-6 weeks

Request Now

Categories: Wireless Microphone Systems , Microphones

The SpeechLine Digital Wireless Microphone Set from Sennheiser includes an SL Table Stand 153-S DW, a MEG 14-40-L-II B gooseneck microphone with integrated LED ring, an SL Rack Receiver DW with power supply, a BA 40 rechargeable battery, and a rackmount kit. Optimized for speech transmission, this flexible wireless set offers speech intelligibility and ease of use for meeting participants, in conference rooms, offices, and huddle rooms.

The table stand features a 5-pin XLR port for connecting to the gooseneck microphone; it connects wirelessly to the receiver and can be charged wirelessly or via included USB cable. The rechargeable battery allows up to 10 hours of operation and an LED provides battery life status. The receiver features a clear visible OLED display for easy setup and operation. The automatic frequency and interference management allows convenient and reliable operation. The microphone set can be controlled and monitored remotely via the Sennheiser Control Cockpit software (available separately).

System

AF Frequency Response	20 Hz to 20 kHz
Dynamic Range	> 120 dB
THD	0.1% at 1 kHz
Audio Sampling	24-bit / 48 kHz
Signal to Noise Rate	> 90 dB
Encryption	AES 256
RF Frequency Range	US: 1920 to 1930 MHz
Modulation	GFSK with back channel
Transmission Method	TDMA, space diversity
Latency	19 ms
Relative Humidity	95% maximum
Operating Temperature	14 to 131°F / -10 to 55 °C
Storage Temperature	-4 to 158°F / -20 to 70°C

Receiver

RF Sensitivity	< -90 dBm
RF Output Channels	Adaptive, up to 250 mW (country-specific)
Audio Output Level	XLR Balanced: Maximum +18 dBu RCA Unbalanced: Maximum +6 dBu
Audio Effects	Low Cut: -3 dB at 120 Hz Equalizer: 7-band graphic equalizer with sound presets Sound Profiles: Female voice, male voice, and media
Display	OLED
Network Protocol	Media Control Protocol, TCP/IP IPv4 (DHCP, manual)/IPv6
Power Supply	12 VDC
Current Consumption	350 mA
Connectors	1 x XLR 2 x RCA 2 x reverse SMA 1 x RJ45 1 x power
Dimensions	8.4 x 1.7 x 6.6" / 21.2 x 4.3 x 16.8 cm
Weight	29 oz / 828 g

Power Supply

Nominal Input Voltage	100 to 240 VAC
Power Frequency	50 or 60 Hz
Input Current	Maximum 120 mA
Power Consumption	Standby: ≤ 0.3 W
Operating Temperature	14 to 131°F / -10 to 55°C
Storage Temperature	-4 to 158°F / -20 to 70°C
Relative Humidity	95%
Dimensions	Not specified by manufacturer
Weight	Approx. 3.5 oz / 100 g

Stand

AF Frequency Response	75 Hz to 20 kHz
Max Input	1.7 V RMS
Input Impedance	30 kOhms
Power Supply	BA 40 accupack
Operating Time	Up to 10 hours
Microphone Connector	5-pin XLR
Operating Temperature	50 to 113°F / 10 to 45°C
Relative Humidity	95%
Dimensions	6.6 x 4.7 x 1.9" / 16.7 x 12.0 x 4.8 cm
Weight	23 oz / 660 g without battery

Battery

Model	BA 40
Capacity	2200 mAh
Output Voltage	3.6 V

Microphone

Pick Up Pattern	Cardioid
Frequency Response	50 Hz to 20 kHz
Acoustic Principle	Gooseneck microphone (condenser)
Output Impedance	< 100 Ohms at 1 kHz
Sensitivity	15 mV/Pa
Maximum Sound Pressure Level (SPL)	130 dB at 1 kHz < 3%
Equivalent Noise Level	37 dB (CCIR) 26 dB (A)
Power Supply	Microphone: 12 to 48 V phantom power Signal Light Ring: 12 to 30 VDC, 1-18 mA, green LED
Current Consumption	3 mA
Connector	5-pin XLR
Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	-13 to 158°F / -25 to 70°C
Length	18.0" / 45.7 cm

Packaging Info

Package Weight	7.65 lb
Box Dimensions (LxWxH)	16 x 13.8 x 2.9"
