Point Of View Camera w H.264 streaming
1 x BC-15PN Main Unit
1 x Standard Lens (attached on camera with lens cap)
1 x Wide-angle Lens (attached with lens caps)
1 x DC 12V power adaptor
1 x Carry Case
The small box design of the BC-15PN makes it incredibly flexible for mounting anywhere. Despite its compact size, this device does not compromise on quality. Equipped with a 1/2.3” 4K CMOS sensor, it captures high-quality images, showcasing incredible details of the subject. Additionally, it supports NDI connection, enhancing its versatility for seamless video streaming and integration into various network-based workflows.
Video format/Resolution 2160p 60/59.94/50/30/29.97/25
1080p 60/59.94/50/30/29.97/25
Image Sensor 1/2.3" CMOS
Effective Pixels (approx.) 12.3Mega Pixels
S/N Ratio 50 dB
Min. Illumination 0.5Lux (F1.0, AGC ON)
Electronic Shutter
1/25(1/30), 1/50(1/60), 1/75(1/90), 1/100(1/120), 1/125(1/150),
1/150(1/180), 1/200(1/210), 1/500(1/600), 1/1000(1/1200),
1/2000(1/2400), 1/4000(1/4800), 1/8000(1/9000) sec
Zoom Ratio 2x Digital Zoom
Gamma Control Standard / Mode1 / Mode2 / Mode3
Iris Control Fixed IRIS (F1.0)
Digital Noise Reductions 2D/3D
On-Screen Display (OSD) English/Simplified Chinese/Traditional Chinese
White Balance Auto, Indoor, Outdoor, OnePush, Color Temp., R/B Gain, Lock
AGC / Gain Control Auto(AGC) / Manual / Lock
(Follow Exposure Mode)
HDR/WDR WDR
Mirror / Flip Image Yes
Focus Mode Full Manual
Panning / Tilting Range ----
Panning / Tilting Speed ----
Preset ----
Focal Length Standard Lens: 6mm
Wide Lens: 2.8mm
Field of View (Horizontal,
Wide)
Standard Lens: H: 38.6, V:21.9, D: 44.1
Wide Lens: H: 75.5, V:46.6, D:82.7
Image Compensation Auto
Video Output HDMI 2.0 x1
Audio Input 3.5mm Line in/Mic in (Stereo)
Tally LED Dual color (Red, Green)
Lens Filter IR cut built-in
Control Protocol DVIP
Remote Control Interface RJ-45: for IP control (DVIP)
Video Compression Format H.265, H.264
Audio Compression Format AAC
Audio Bitrate 128Kbps
HD IP Interface 10/100/1000M
Streaming Protocols RTMP(S), SRT, NDI
First Stream Supported
Resolution
1920x1080
1280x720
1024x576
960x540
640x480
640x360
Second Stream Supported
Resolution ----
Video Bitrate 1Mbps ~ 7Mbps
Video Bitrate Mode VBR, CBR
Encoding Frame rate 50Hz: 1-50fps
60Hz: 1-60fps
POE IEEE 802.3af
F/W Update Ethernet
IR Control ----
Camera Control Unit RMC-300 series/BC View Assist APP
Tripod Mount 1/4-20 UNC
Optional Accessories ----
Color Black
Operating Temp. Range 0~40 °C
Power DC 12V 9W PoE
