The AV-UHS5M6G NDI Input/Output Expansion Board from Sony enables you to input NDI and NDI|HX signals to an AV-UHS500 video switcher. Use this board to create an IP streaming system that covers video transmission, camera control, and more using a single LAN cable. The board is inserted into the back of the switcher, avoiding the complex configurations of external converters. Ideal for sports and other live events, the AV-UHS5M6G board features two RJ45 LAN ports that offer a total maximum bandwidth of 2GB. Features include an integrated frame synchronizer and a genlock function that supports black burst and tri-level syncing.
| LAN Interface | 2 x RJ45, 1 GB Each |
| Signal Support | Input/Output: NDI Input Only: NDI|HX, NDI|HX2 |
| Synchronization | Genlock |
| Certifications | JACO ISO 14001 UKAS |
| Dimensions | Not Specified by Manufacturer |
| Weight | Not Specified by Manufacturer |
| Package Weight | 1.26 lb |
| Box Dimensions (LxWxH) | 9.5 x 7 x 3.1" |
