Key Features
The Atomos Ninja is a compact 5.2″ 4K HDMI monitor‑recorder designed for filmmakers, creators, and gamers. It supports DCI 4K60 monitoring and can record ProRes RAW up to 6K with compatible cameras. Its familiar body design ensures compatibility with existing Atomos accessories, making it easy to integrate into any workflow.
Powered by AtomOS 11, the Ninja offers a refreshed, intuitive interface with advanced monitoring tools including Focus Peaking, Zoom, Atomos & ARRI False Color, EL Zone, Safe Areas, RecordAssist, PlayBackAssist, SegmentPro, and Cine Guides. AtomHDR processing provides instant Log‑to‑HLG/PQ conversion for accurate HDR previewing.
The 5.2″ IPS touchscreen delivers 1920×1080 resolution, 1000‑nit brightness, 10‑bit processing, and Rec.709 color accuracy, with support for Calibrite ColorChecker calibration for consistent, reliable color monitoring.
The Ninja supports a wide range of Log formats from Sony, ARRI, JVC, RED, FUJIFILM, Nikon, Panasonic, and Canon. Users can load custom 3D LUTs and output HDR in Log, HLG, PQ, or Dolby Vision.
Featuring HDMI input/output, the Ninja handles DCI 4K60 for monitoring, recording, and playback. It supports 3.5K RAW at 60 fps with select cameras and RAW over HDMI up to 6K30 with more than 55 supported models. Gamers can record UHD 4K HDR gameplay directly to the Ninja for fast sharing.
Pairing the Ninja with the Atomos CONNECT module unlocks cloud workflows including C2C, Atomos Edit, RemoteView, and adds 12G‑SDI, AirGlu sync, Wi‑Fi 6, and GigE Ethernet for live streaming and HDMI↔SDI conversion. Adding AtomX CAST transforms the Ninja into a 4‑input HDMI switcher with overlays and USB UVC output.
Recording is supported via Atomos Master Caddy II/III, AtomX SSDmini, and CFAST II (with adapter). Power options include NP‑F batteries, USB‑C PD (30W), or DC input via dummy battery. Control is available through touchscreen navigation, multifunction buttons, Auto HDMI triggers, and optional Bluetooth/RF/LANC when using CONNECT.
Category | Specification |
Dimensions (W × H × D) | 151 mm × 91.5 mm × 31 mm (5.95″ × 3.6″ × 1.2″) |
Weight | 360 g / 12.7 oz |
Mounting Points | Top: 1× 1/4″‑20 or 3/8″ with anti‑rotation points; Bottom: 1× 1/4″‑20 or 3/8″ with anti‑rotation points |
Ambient Operating Temperature | Up to 40°C |
Body Material | Aluminium alloy chassis + ABS polycarbonate rear enclosure |
Cooling System | Heat sink + actively controlled fan |
Tally Light | Rear LED |
Multi‑Function Button | Power / Lock screen |
AtomXpansion Slot | Integrated into battery slot |
Touch Screen | Capacitive touch |
Input Voltage | 6.2V – 16.8V |
Operating Power | 10–22W |
Compatible Batteries | NP‑F / L‑Series |
Battery Runtime | 5200 mAh: up to 2 hours; 7800 mAh: up to 3 hours |
DC‑In Connector | Locking DC jack (5.5 mm OD / 2.1 mm ID) via Battery Eliminator |
D‑Tap Power | Via Battery Eliminator + optional D‑Tap → DC‑Barrel cable |
Fan Control | Low / Medium / Auto / Turbo Cool / Dim Display |
Display Panel | SuperAtom IPS (capacitive touch) |
Display Size | 5.2″ |
Resolution | 1920 × 1080 |
Viewing Angle | 178° H/V |
PPI | 423 |
Bit Depth | 10‑bit (8+2 FRC) |
Backlight Type | Edge‑lit |
Brightness | 1000 nits |
Aspect Ratio | 16:9 |
Color Gamut | Rec.709 |
Gamma Profiles | Sony S‑Log/S‑Log2/S‑Log3, Canon C‑Log/C‑Log2/C‑Log3, ARRI Log CEI160–1600/LogC4, Panasonic V‑Log, JVC J‑Log1, RED LogFilm/Log3G10/Log3G12, Fujifilm F‑Log/F‑Log2, PQ (HDR10), HLG, Nikon N‑Log, Z CAM Z‑Log2, Olympus OM‑Log400/Flat, Leica L‑Log |
Gamut Profiles | BT.2020, DCI‑P3, DCI‑P3 65, Sony SGamut/SGamut3/SGamut3.cine, Canon Cinema/DCI‑P3/DCI‑P3+/BT.2020, Panasonic V‑Gamut, ARRI Alexa Wide Gamut, Rec.709, JVC LS300, RED DragonColor/DragonColor2/RedColor2/RedColor3/RedColor4/RedWideGamut |
3D LUT Display | .cube format (17 & 33‑point LUTs) |
3D LUT Output | Loop out |
3D LUT 50/50 Split | Compare option in LUT menu |
Monitoring Modes | Native / HLG / PQ / 3D LUT |
HDR Output Conversion | Camera Log → HLG/PQ |
Calibration Support | Computer‑driven calibration |
Display Controls | Backlight, Lift, Gamma, Gain |
AtomHDR | Technical Log → HDR EOTF |
3D LUT Functions | Load .cube LUTs into 8 slots; monitor, bake into recordings, or apply to HDMI/SDI output |
Legalize | Full → Legal range conversion |
HDMI Input | 1× HDMI 2.0 |
SDI Input | 1× 12G‑SDI (requires Atomos CONNECT) |
Input Bit Depth | 8/10‑bit video; up to 12‑bit RAW |
Chroma Subsampling | YCbCr 4:2:0 & 4:2:2 |
HDR (HDMI) | Auto detection |
HDMI Metadata | RAW: WB, EI, shutter angle, iris, ISO, gamma, gamut |
SDI Metadata | File name (ARRI, Canon, RED, Sony), RAW metadata (requires CONNECT) |
File Naming | Standard; Scene/Shot/Take; Rolling Scene/Shot/Take |
HDMI Output | 1× HDMI 2.0 |
Output Chroma Subsampling | 4:2:2 |
Output Bit Depth | 10‑bit |
SDI → HDMI Conversion | Supported (requires CONNECT) |
Audio Quality | 24‑bit / 48 kHz PCM |
HDMI Audio | 8‑channel, 24‑bit |
SDI Audio | 12‑channel, 24‑bit |
Analog Audio In | 3.5 mm jack |
Analog Audio Out | 3.5 mm headphone jack |
Audio Input Delay | Frame delay + auto offset calibration |
Timecode (HDMI) | Embedded |
Timecode (SDI) | Embedded (requires CONNECT) |
Time of Day | Supported |
Wireless Sync | AirGlu SYNC (requires CONNECT) |
RF Range | 300 m (requires CONNECT) |
Bluetooth Range | 10–15 m LOS (requires CONNECT) |
6K RAW | Up to 6Kp30 (HDMI & SDI with CONNECT) |
4K RAW | Up to 4Kp60 (HDMI/SDI with CONNECT) |
3.5K Anamorphic RAW | Up to 3.5Kp60 (HDMI) |
2K RAW | Up to 2Kp240 (SDI with CONNECT) |
4K DCI | Up to 4Kp60 |
4K UHD | Up to UHDp60 |
2K DCI | Up to 2Kp60 (SDI with CONNECT) |
1080p | Up to 1080p120 |
1080 PsF | Pulldown only |
1080i | 50/60i |
720p | Up to 720p60 |
Recording Codecs | ProRes RAW/RAW HQ; ProRes HQ/422/LT; DNxHD 220x/220/145/36; DNxHR HQX/HQ/SQ/LB; H.265 XQ/HQ/MQ/LQ |
C2C Upload | H.265 to Atomos Edit, Frame.io, Sony CI (requires CONNECT) |
Proxy Recording | ProRes RAW/ProRes/DNx + H.265 (requires CONNECT) |
Pre‑Roll | 8s HD / 2s 4K (ProRes & DNx) |
Timelapse | Supported |
Gang Control | AirGlu SYNC (requires CONNECT) |
Scheduled Recording | Time‑of‑day or delayed |
Playback | Playlist, Loop, ProRes RAW, ProRes, DNx, H.265 |
Multi‑Input Switching | Requires AtomX CAST |
Supported Media | Master Caddy II/III, SSDmini, CFast 2.0 (via adapter) |
File System | exFAT |
Interface | SATA 3.0 |
On‑Screen Tools | Waveform, RGB Parade, Vectorscope, Zoom, Peaking, Zebra, False Color (Atomos/ARRI/EL Zone), Frame Guides, Social Guides, Safe Areas, Grid, Anamorphic Desqueeze |
Frame Grab + Onion Skin | 1920×1080 frame grab + overlay |
Signal Processing | 4K→HD downscale, DCI crop, pulldown conversion |
Remote Control (HDMI) | Canon/Sony/Atomos protocols |
Remote Control (SDI) | ARRI/Canon/Ikegami/JVC/Panasonic/RED/Sony (requires CONNECT) |
Serial Control | LANC via 2.5 mm jack |
Bluetooth LE | Via AtomRemote app (requires CONNECT) |
Wireless RF | AirGlu Gang Control (requires CONNECT) |
Cut & Tag | FCP XML (up to 10 tags) |
Supported Applications | Final Cut Pro, Premiere, Avid, Edius, SCRATCH, Baselight |
